4.14.4 Fine adjust the print specifications (Adjust print parameters)
(1) Function
●Starts from the Print description screen.
●Current message print specifications “character height”, “character width”, “print start delay” and “Pulse rate
div. Factor” settings are easily set.
●Since changes to the set value are immediately reflected in the printing, the changes be easily confirmed while
printing.
●After setting in character units or mm units, fine adjust in scan units.
●When you want to input in mm units, input “Line speed” in the print specifications screen.
“Adjust print parameters” screen
(Note) If various settings are changed when the printing is performed frequently,
the faults such as "Print Overlap fault", "Print Data Changeover In
Progress V" or "Invalid Print Start Timing" may occur.
To Next Page
