Print description
2015.07.0712:45
M
Manual
Startup
Menu
Com=0
[Stop ]
Ink operating time １００(hours)
Cumulative op. time １００(hours)
Print count １０００(prints)
Ink pressure ０．０００(MPa；standard value:０．２５０)
Change
message
Select
message
Overwrite
message
Adjustprint
parameters
Operation
management
Message name[ ]
《
−
》
＋
Maintenance
Auxiliary
function
Environment
setupmenu
4.1 Print description screen (initial screen)
(1) Overview
●The display is shifted to the screens for message edit and Maintenance, Auxiliary function, and
Environment setup menu screens by pressing each button.
●The print image can be confirmed at the “Print layout” area.
Item Description Reference
Change message ●Edits and corrects current message. 4.2
Select message ●Calls and prints saved messages. 4.3
Overwrite message ●Overwrites the current message. 4.4
Adjust print parameters ●Creates and edits messages different from the current message. 4.14.4
Operation management ●Displays operation status. 5.2
Maintenance ●Displays the maintenance menu. 5
Auxiliary function ●Displays the auxiliary functions menu. 7
Environment setup menu ●Displays the environment setup menu 6
Select login user ●Logs in again as a different user from currently logged in user. 6.4
Create/Edit message ●Creates and edits messages different from the current message. 4.5
Print count reset ●Reset the print count to zero (0). 4.1
The Shutdown is displayed
during ink ejection.
The Startup is displayed
during stop.
Displays the
print layout.
Displays the operation
management
information.
When the Menu is pressed,
the display is switched.
Displays the zoom in
or zoom out.
Displays the scroll.
For details
regarding the
printing method
display, refer to
"4.14.1 Set the
character
height,
character width,
and
orientation."
Print count is
reset to 0.
If is indicated in
off-line state.
To Next Page
