General| Engine Type | 449cc liquid-cooled single-cylinder four-stroke |
|---|---|
| Bore x Stroke | 96.0mm x 62.1mm |
| Compression Ratio | 12.5:1 |
| Induction | Programmed Fuel Injection (PGM-FI), 46mm throttle body |
| Ignition | CDI |
| Transmission | Close-ratio five-speed |
| Final Drive | #520 chain; 13T/48T |
| Front Brake | Single 240mm disc with twin-piston caliper |
| Rear Brake | Single 240mm disc |
| Front Tire | 80/100-21 |
| Rear Tire | 120/80-19 |
| Seat Height | 37.6 inches |
| Ground Clearance | 13.2 inches |
| Front Suspension | 12.2 inches travel |
| Rear Suspension | Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability; 12.4 inches travel |
| Rake | 27° 04' |
| Trail | 4.6 inches |
| Wheelbase | 58.3 inches |
| Curb Weight | 249 pounds |
