56
SERVICING YOUR GENERATOR
SPARK ARRESTER SERVICE
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
If the engine has been running, the muffler will be very hot. Allow the
muffler to cool before servicing the spark arrester.
Clean the spark arrester as follows:
1. Remove the two 5 mm screws, and remove the spark arrester.
2. Use a brush to remove carbon deposits from the spark arrester screen.
Be careful to avoid damaging the screen.
The spark arrester must be free of breaks and tears. Replace the
spark arrester if it is damaged.
3. Install the spark arrester in the reverse order of removal.
5 mm SCREWS SPARK ARRESTER
31Z236120.book 56 ページ ２０１５年１２月１０日 木曜日 午前１１時４３分
