77
TECHNICAL INFORMATION
Specifications
Dimensions
Engine
Generator
Tuneup
Specifications may vary according to the types, and are subject to
change without notice.
Model EM4000SX EM5000SX EM6500SX
Type AT1 type
Description code EBRC EBMC EBJC
Length 41.1 in (1,043 mm)
41.4 in (1,051 mm)
Width 27.8 in (706 mm)
Height 28.3 in (719 mm)
Dry mass [weight]
203.9 lbs (92.5 kg) 228.2 lbs (103.5 kg) 233.7 lbs (106.0 kg)
Model iGX270 iGX390
Engine type 4-stroke, overhead valve, single cylinder
Displacement
[Bore×Stroke]
16.5 cu-in (270 cm
3
)
[3.03×2.28 in
(77.0×58.0 mm)]
23.7 cu-in (389 cm
3
)
[3.46×2.52 in
(88.0×64.0 mm)]
Compression ratio 8.5:1 8.2:1
Engine speed 3,600 rpm
Cooling system Forced air
Ignition system CDI magneto
Oil capacity 1.2 US qt (1.1 L)
Fuel tank capacity 6.21 US gal (23.5 L)
Spark plug BPR5ES (NGK) · W16EPR-U (DENSO)
Model EM4000SX EM5000SX EM6500SX
Type AT1 type
AC
output
Rated voltage 120 V/240 V
Rated frequency 60 Hz
Rated current 30.0 A/15.0 A 37.5 A/18.8 A 45.8 A/22.9 A
Rated output 3.6 kVA 4.5 kVA 5.5 kVA
Maximum output 4.0 kVA 5.0 kVA 6.5 kVA
DC output Only for charging 12V automotive batteries.
Maximum charging output = 8.3 A
ITEM SPECIFICATION MAINTENANCE
Spark plug gap
0.028–0.031 in (0.7–0.8 mm)
Refer to page 54
Valve clearance (cold) IN: 0.15±0.02 mm
EX: 0.20±0.02 mm
See your authorized
Honda dealer.
Other specifications No other adjustments needed.
31Z236120.book 77 ページ ２０１５年１２月１０日 木曜日 午前１１時４３分
