5-5
dummyheaddummyhead
FUEL SYSTEM
AIR CLEANER REMOVAL/INSTALLATION
BREATHER TUBE
8.5 N·m (0.9 kgf·m, 6.3 lbf·ft)
AIR CLEANER
PACKING
AIR CLEANER ELEMENT
NUT(6 mm) (2)
AIR CLEANER COVER
AIR CLEANER CASE
INSTALLATION:
Connect one end to the crankcase cover hole
and then the other end to the air cleaner case
(page 2-5).
If it is hard to install, apply engine oil to the
tube end.
INSTALLATION:
Before installation, clean the inside
of the case with compressed air.
