10-9
dummyheaddummyhead
CRANKSHAFT/PISTON/VALVES
OIL FILLER CAP/EXTENSION
REMOVAL/INSTALLATION
Drain the engine oil (page 3-3).
O-RING
OIL FILLER CAP/DIPSTICK
OIL FILLER PACKING
12 N·m (1.2 kgf·m, 9 lbf·ft)
CT BOLT (6 x 14 mm) (2)
OIL FILLER EXTENSION
INSTALLATION:
Be sure that no dust or foreign materials enter
the crankcase.
