(1)
(2)
(5)
(3)
(1) seat lock lever
(2) seat
(3) prongs
(4) hooks
(5) studs
(6) grommets
(5)
(4)
(3)
(6)
(4)
150
Seat Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Press down on the seat until locks.
Installation
Slide the seat ( ) back and lift it.
Removal
Pull the seat lock lever ( ) at the right side of the seat.
Insert the prongs ( ) into the hooks ( ) on the frame and press the
studs ( ) into the grommets ( ).
The seat must be removed for the air cleaner, spark plug, battery and
fuse maintenance and to access the owner’s manual and tool kit.
1.
2.
1.
2.
1
3
6
4
5
2
139
０９／０５／１８ １０：１４：０１ ３１ＨＮ２６９０ ０１５９
