(4)
(1)
(3) (5) (6) (7)
(2)
(8)
(10) (9)
(1) RESET button
(TRX500FA)
(2) odometer/tripmeter
select button
(3) 4WD indicator
TRX500FA
(4) high oil/coolant
temperature indicator
(5) neutral indicator
(6) reverse indicator
(7) multi-function display
(8) hour select button
(TRX500FA)
(9) minute select button
(TRX500FA)
(10) adjust button
(TRX500FA)
14
Indicators & Displays
Instruments & Controls
The indicators and displays on your ATV keep you informed, alert you
to possible problems, and make your riding safer and more enjoyable.
Refer to the indicators frequently. Their functions are described on the
following pages.
