3.96 US gal (15.0 )
0.66 US gal (2.5
)
(2)(1)
(1) fuel gauge (2) segment RES
(1)
(2)
TRX500FA
TRX500FA
TRX500FPA
TRX500FPA
32
Fuel Gauge
Indicators & Displays
Instruments & Controls
When segment RES ( ) flashes, you should refill the tank as soon as
possible. The amount of fuel remaining when the flashing starts is
approximately:
The fuel gauge liquid crystal display ( ) shows the approximate fuel
supply available. The fuel tank capacity is:
All segments will flash, when the fuel gauge function is fails. See your
Honda dealer.
1
2
０９／０５／１８ ０９：５６：３７ ３１ＨＮ２６９０ ００４１
