Honda TRX500FA - Multi-Function Display

(3)
(1)
(2)
(1)
(4)
(6)(7)(8) (9)
(10)
(5)
(4)(5)
(7)
(2)
(3)
TRX500FA
(1) multi-function display
(2) drive mode indicator
(3) gear position indicator
(4) speedometer
(5) fuel gauge
(9)
(For TRX500FPA)
TRX500FPA
(6) hourmeter (TRX500FA)
(7) odometer/tripmeter
(8) digital clock (TRX500FA)
(9) oil change indicator
(10) digital clock/hourmeter
(TRX500FPA)
21
Multi-function Display
Indicators & Displays
Instruments & Controls
The multi-function display ( ) includes the following functions:
The digital clock will reset if the battery is disconnected.
The tripmeter will reset if the battery is disconnected.
USA: Displays read in mph and miles.
Canada: Displays read in km/h and kilometers.
1
Speedometer
Odometer
Tripmeter
Drive mode indicator
Gear position indicator
Oil change indicator
Digital clock
Hourmeter
Fuel gauge
