(2)
(1)
(1) engine guard
(2) skid plates
(3) front boot guards
(4) front driveshaft guards
(3)
(4)
208
Servicing Your Honda
Guards
Saf ety PrecautionsRefer to on page .
The engine guard ( ) protects the engine crankcase, and the skid plates
( ) protect the frame and rear final gear case.
The front boot guards ( ) protect the rubber driveshaft boots, and the
front driveshaft guards ( ) protect the front driveshaft.
Check all these parts for cracks or damage, and replace them as required.
If any fasteners are loose, tighten them securely.
139
1
2
3
4
