(1) (1)
TRX500FA
(1) gear position indicator
TRX500FPA
23
Gear Position Indicator
Indicators & Displays
Instruments & Controls
The gear position indicator ( ) shows the gear position when the
ignition switch is in the ON ( ) position.
The indicator displays: N for neutral, R for reverse, D for drive, L for
low, and 1 5 for the five forward positions in the ESP mode.
‘‘- -’’ will be displayed on the gear position indicator when the
transmission is not shifted into gear properly. Before riding, check that
the gear position is properly displayed on the gear position indicator.
1
