6 - 2
Using the Function Keys
Name Key Function
Backlight
Numeric Keyboard
Turns the keyboard backlight on and off.
&
QWERTY Keyboard
Backspace Moves the cursor back one space each time the key is pressed. If you
are typing text, it deletes the previous character each time it is pressed.
Enter (ENT) Confirms data entry.
Escape
(ESC)
Numeric Keyboard
Cancels the current action.
QWERTY Keyboard
Power Key Puts the terminal in and wakes the terminal from Suspend Mode; see
Suspend Mode on page 3-16.
SCAN Key Activates the scan and “wakes” the terminals from Sleep Mode. Its
position allows convenient one-handed image-taking and/or bar code
decoding.
&
Turns the flashlight on and off. The flashlight is located on the back panel
of the terminal.
Space (SP)
Numeric Keyboard
Moves the cursor one space.
QWERTY Keyboard
Tab Moves the cursor to the next tab stop or the next control (on a form).
