FC1: Operation for Legally Relevant Functionalities 5
5.3.2 Different Types of Device Displays
The main purpose of a Fiscal display is the indication of legally relevant
results according to applicable standards.
For an FC1 flow computer, the
Flow Conversion AFB provides a fiscal
display that shows the volume at base conditions (Vb) in a preferential way.
Additionally, some other important values are displayed in the regular way.
Main display is the name for a display of an AFB or Basic System function-
ality, which includes a composition of the most important results of that func-
tionality.
Where appropriate, there are further subordinate displays belonging to the
same AFB or functionality.
The basic display is the display that is invoked directly after starting the
device.
For an FC1 flow computer, the fiscal display of the first
Flow Conversion
AFB
is chosen as basic display.
Home is a special display visualizing the software structure of the individual
device.
Single software parts (such as AFBs) and selected other functionalities that
have to be reached easily (e.g. clock settings, language switching) are
shown as icons. These icons are labeled with the name of the corresponding
functionality.
In case of an AFB, the label shows the user-defined name for this AFB or, if
no user-defined name has been parameterized, the default name.
The parameterization supports the grouping of AFBs in user-defined struc-
tures. If an AFB has been assigned to a structuring folder in this way, the
name of the related folder appears as a hint when selecting the correspond-
ing button on the screen.
