FC1: Technical Data 7
7 FC1: Technical Data
7.1 General
Dimensions/housing
Plug-in unit in 19” design, 3 height units (3HU), 1/2
or 1/3 width
Overall depth without plugs approximately 170 mm,
with plugs approximately 220 mm
Process interfacing at the rear, operation panel at
the front
Ambient conditions Ambient temperature range −10 °C to +55 °C
Humidity < 90
%, non-condensing
Installation outside Ex zones 0, 1, 2 only
IP protection class IP20
Storage temperature −25°C to +60°C
Weight (fully equipped)
• 1/3 device width: approx. 1.3 kg
• 1/2 device width: approx. 2.1 kg
Power supply Power supply 24 V DC +/− 20
%, power consump-
tion up to 12 W (typically 5 W)
Optional: 230 V AC via external power supply
Display/Operation
panel
4.3“ TFT color display with touch screen,
480 × 272 × 3 pixels, LED background lighting
4 navigation and 2 function keys
2 multicolor LEDs for power and status indication
Table 14: General technical data
