Honeywell FUSION User Manual

FUSION DVR Digital Recording and Transmission System
4–6
4.6 SCREEN DIVISION MENU, CONTINUED
4
th
Four Cameras
Displays cameras 13-16 in the Video Display Area.
To return to a different Multi-Camera View, select a
different Screen Division option from the Screen
Division menu.
1
st
Eight Cameras
Displays cameras 1-9 in the Video Display Area. To
return to a different Multi-Camera View, select a
different Screen Division option from the Screen
Division menu.
2
nd
Eight Cameras
Displays cameras 10-16, 8, and 9 in the Video
Display Area. To return to a different Multi-Camera
View, select a different Screen Division option from
the Screen Division menu.
Multi-Camera View
Displays a group of cameras within the Video
Display Area
All Camera View
Displays all 16 cameras within the Video Display
Area.
Multi-Camera View
Displays a group of cameras within the Video
display Area.
Multi-Camera View
Displays a group of cameras within the Video
display Area.
Full Screen
The Full Screen Option allows the Video Display
Area to use the entire viewable area on the monitor.
When this is selected, no menu options are visible.
Activate the Full Screen Option by clicking on the
Full Screen Button within the Screen Division Menu.
Deactivate Full Screen mode by right clicking on the
screen.
AUTO-SEQUENCE
Sequences through the Screen Divisions sets.
For example, selecting the 1A and then the Loop
button will sequence through 1A,2A,3A,4A and then
repeat. This option is not available for the 7,10 and
13 screen divisions.
