12 796689 (4188-658) i2_04/07
Fire condition
Fire
Fire Routing
Activated
Fire Protection
Activated
Fire event(s) from detectors or manual call
points in zone(s) are indicated and logged at
the panel.
The red Fire light is lit.
The first fire information is given in the top
portion of the display, while the latest fire in
the lower portion.
The local buzzer sounds to announce each
fire event.
If the facilities are available and configured
for use, then the Fire Routing and Fire
Protection lights are lit
.
System alarm sounders are active.
Follow site evacuation procedures.
Number of
active fires
First fire:
Zone number
Device or location label
Latest fire
Device of location label
First fire:
device number
Number of
zones in fire
To Next Page
