2-3
Installing the Switch
Installation Procedures
Installing the Switch
Installation Procedures
Summary
Follow these steps to install the switch. The rest of this chapter provides
details on these steps.
1. Prepare the installation site (page 2-5). Ensure the physical environ-
ment is properly prepared, including having the correct network cabling
ready to connect to the switch and having an appropriate location for the
switch. Please see page 2-4 for some installation precautions.
2. Install mini-GBICs (optional—page 2-7). The switch has two slots for
installing mini-GBICs. Depending on where you will install the switch, it
may be easier to install the mini-GBICs first. Mini-GBICs can be hot
swapped—they can be installed or removed while the switch is powered
on.
3. Verify the switch passes self test (page 2-9). Plug the switch into a
power source and observe the LEDs on the switch’s front panel that they
indicate correct switch operation.
4. Mount the switch (page 2-11). The Series 2510 Switch can be mounted
in a 19-inch telco rack, in an equipment cabinet, on a wall, or on a
horizontal surface.
5. Connect power to the switch (page 2-15). Once the switch is mounted,
plug it into the nearby main power source.
6. Connect the network cables (page 2-16). Using the appropriate
network cables, connect the network devices to the switch ports.
7. Connect a console to the switch (optional—page 2-17). You may wish
to modify the switch’s configuration, for example, to configure an IP
address so it can be managed using a web browser, from an SNMP network
management station, or through a Telnet session. Configuration changes
can be made easily by using the included console cable to connect a PC
to the switch’s console port.
At this point, the switch is fully installed. See the rest of this chapter if you
need more detailed information on any of these installation steps.
