HP 5120 EI Switch Series User Manual

225
Figure 66 SSH client configuration interface 2)
Click Open to connect to the server. If the connection is normal, you will be prompted to enter the
username. After entering the username client002, you can enter the configuration interface of the server.
SSH client configuration examples
When switch acts as client for password authentication
Network requirements
As shown in Figure 67, Switch A (the SSH client) must pass password authentication to log in to Switch B
(the SSH server) through the SSH protocol. Configure the username client001 and the password aabbcc
for the SSH client on Switch B.
Figure 67 Switch acts as client for password authentication
SSH server SSH client
Switch B Switch A
Vlan-int1
10.165.87.136/24
Vlan-int1
10.165.87.137/24
Configuration procedure
1. Configure the SSH server
# Generate the RSA key pairs.
<SwitchB> system-view
