HP 5120 EI Switch Series User Manual

235
To do…
Use the command…
Remarks
user view
quit
These three commands function in
the same way.
SFTP client configuration example
Network requirements
As shown in Figure 69, an SSH connection is established between Switch A and Switch B. Switch A, an
SFTP client, logs in to Switch B for file management and file transfer. An SSH user uses publickey
authentication with the public key algorithm being RSA.
Figure 69 Network diagram for SFTP client configuration
SFTP server SFTP client
Switch B Switch A
Vlan-int1
192.168.0.1/24
Vlan-int1
192.168.0.2/24
Configuration procedure
NOTE:
During SFTP server configuration, the client public key is required. Use the client software to generate
RSA key pairs on the client before configuring the SFTP server.
1. Configure the SFTP client
# Create VLAN-interface 1 and assign an IP address to it.
<SwitchA> system-view
[SwitchA] interface vlan-interface 1
[SwitchA-Vlan-interface1] ip address 192.168.0.2 255.255.255.0
[SwitchA-Vlan-interface1] quit
# Generate the RSA key pairs.
[SwitchA] public-key local create rsa
The range of public key size is (512 ~ 2048).
NOTES: If the key modulus is greater than 512,
It will take a few minutes.
Press CTRL+C to abort.
Input the bits of the modulus[default = 1024]:
Generating Keys...
++++++++
++++++++++++++
+++++
++++++++
# Export the host public key to file pubkey.
[SwitchA] public-key local export rsa ssh2 pubkey
[SwitchA] quit
