HP Elite x2 1011 G1 Maintenance And Service Guide

1 Product description
Category Description
Product Name HP Elite x2 1011 G1
Processor
●
Intel® Core™ i7 M-5Y71 processor
●
Intel Core i5 M-5Y51 processor
●
Intel Core i3 M-5Y10c processor
Chipset Intel soldered-on chipset (SoC)
Graphics Intel HD unified memory architecture (UMA) Graphics
Panel 11.6-in, TouchScreen, full-high definition (FHD), BrightView (BV), (1920×1080), in-plane switching
(IPS), 50% CG, typical brightness 400 nits, eDP 1.3, ultra-slim with and without digitizer
11.6-in, TouchScreen, high definition (HD), BV, (1366×768), IPS, 50% CG, typical brightness 400 nits,
eDP 1.2, ultra-slim with and without digitizer
Memory 2 SODIMM slots DDR3L-1600MHz
Support for DDR3L-1600MHz
Support for dual channel
Supports up to 8192-MB maximum system memory
Supports 8192-MB (16-GB, 256-MB×16×4, qty 4) and 4096-MB (8-GB @ 128-MB×32×2, qty 4)
memory configurations
Primary storage Support for M2 solid-state drive, SS 2280
Support for the following solid-state drives:
●
512-GB, M2, SATA-3 solid-state drive
●
256-GB, M2, SATA-3 solid-state drive
●
256-GB, M2, SATA-3 solid-state drive supporting triple-level cell (TLC)
●
256-GB, M2, SATA-3 self-encrypting drive (SED) solid-state drive supporting Opal 2
●
256-GB, M2, SanDisk X110 locked solid-state drive
●
180-GB, M2, SATA-3 solid-state drive
●
180-GB, M2, SATA-3 SED solid-state drive supporting Opal 2
●
128-GB, M2, SATA-3 solid-state drive
●
128-GB, M2, SATA-3 solid-state drive supporting TLC
Audio and video 2.0-MP (1080p) front-facing webcam
5.0-MP (1080p) rear-facing webcam
Dual array microphones
HD audio with DTS Studio Sound
Stereo speakers (2)
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
1

HP Elite x2 1011 G1 Specifications

General

Stepping	F0
Tjunction	95 °C
Processor code	SR23L
Processor cache	4 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ M
Processor series	Intel Core M-5Y Mobile series
Processor threads	4
Processor codename	Broadwell
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor package size	30 x 16.5 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.6 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	14 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Scenario Design Power (SDP)	3.5 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	256 GB
Display diagonal	11.6 \
Touch technology	Multi-touch
Graphics card	HD Graphics 5300
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Processor ARK ID	84669
Processor socket	BGA 1234
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	-
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery capacity	- mAh
Battery life (max)	9 h
Platform	Windows
Operating system installed	Windows 8.1 Pro

Weight and Dimensions

Depth	192.7 mm
Width	298 mm
Height	10.7 mm
Weight	780 g
