HP Elite x2 1011 G1 Maintenance And Service Guide

Display panel assembly
Description Spare part number
11.6-in, TouchScreen, FHD, BV, (1920×1080), IPS, 50% CG, typical brightness 400 nits, eDP 1.3, ultra-
slim with digitizer display panel assembly
793736-001
11.6-in, TouchScreen, FHD, BV, (1920×1080), IPS, 50% CG, typical brightness 400 nits, eDP 1.3, ultra-
slim without digitizer display panel assembly
804352-001
11.6-in, TouchScreen, HD, BV, (1366×768), IPS, 50% CG, typical brightness 400 nits, eDP 1.2, ultra-slim
with digitizer display panel assembly
793737-001
11.6-in, TouchScreen, HD, BV, (1366×768), IPS, 50% CG, typical brightness 400 nits, eDP 1.2, ultra-slim
without digitizer display panel assembly
804351-001
Back cover 793725-001
Before removing the disassembling the slate, follow these steps:
1. Turn off the slate. If you are unsure whether the slate is off or in Hibernation, turn the slate on, and then
shut it down through the operating system.
2. Disconnect the power from the slate by unplugging the power cord from the slate.
3. Disconnect all external devices from the slate.
Remove the display panel assembly:
1. Place the slate on a flat work surface with the docking connector toward you.
2. Remove the speaker grille (1) that covers the display panel screws.
The speaker grille is available using spare part number 793734-001.
3. Remove the six Phillips PM1.5×8.3 screws (2) and the three Phillips PM1.5×3.5 screws (3) that secure
the display panel assembly to the bottom cover.
CAUTION: Do not completely separate the display panel assembly from the bottom cover in the next
step. There are 2 ribbon cables connecting the display panel assembly to the system board that can be
damaged if too much separation is achieved.
Display panel assembly 35

HP Elite x2 1011 G1 Specifications

General

Stepping	F0
Tjunction	95 °C
Processor code	SR23L
Processor cache	4 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ M
Processor series	Intel Core M-5Y Mobile series
Processor threads	4
Processor codename	Broadwell
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor package size	30 x 16.5 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.6 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	14 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Scenario Design Power (SDP)	3.5 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	256 GB
Display diagonal	11.6 \
Touch technology	Multi-touch
Graphics card	HD Graphics 5300
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Processor ARK ID	84669
Processor socket	BGA 1234
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	-
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery capacity	- mAh
Battery life (max)	9 h
Platform	Windows
Operating system installed	Windows 8.1 Pro

Weight and Dimensions

Depth	192.7 mm
Width	298 mm
Height	10.7 mm
Weight	780 g
