6 Removal and replacement procedures –
Keyboard base
NOTE: This chapter provides removal and replacement procedures for Authorized Service Provider only
components. Components described in this chapter should only be accessed by an authorized service
provider. Accessing these components can damage the keyboard base or void the warranty.
There are as many as 49 screws that must be removed, replaced, and/or loosened when servicing
the keyboard base. Make special note of each screw size and location during removal and replacement.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your keyboard base, go to http://partsurfer.hp.com, select your country or region, and
then follow the on-screen instructions.
Bottom cover
Description Spare part number
Bottom cover 793710-001
Rubber Kit (includes bottom cover rubber feet) 804348-001
Before disassembling the keyboard base, follow these steps:
1. Turn off the keyboard base. If you are unsure whether the keyboard base is off or in Hibernation, turn
the keyboard base on, and then shut it down through the operating system.
2. Disconnect the power from the keyboard base by unplugging the power cord from the keyboard base.
3. Disconnect all external devices from the keyboard base.
Remove the bottom cover:
1. Turn the keyboard base upside down on a flat work surface with the front edge toward you.
2. Remove the eleven Torx8 T8M2.0×4.3 screws (1) secure the bottom cover to the keyboard base.
74 Chapter 6 Removal and replacement procedures – Keyboard base
