HP Elite x2 1011 G1 Maintenance And Service Guide

Item Description Spare part number
NOTE: The smart card reader board spare part kit does not include the smart card reader
board cable. The smart card reader board cable is included in the Keyboard Base Cable Kit,
spare part number 793721-001.
(7) Battery, 6-cell, 21-WHr, 0.95-AHr, LI (includes cable) 750550-005
(8) Power connector cable 793714-001
(9) Keyboard base system board (includes docking/adapter port, USB port, and audio jack) 806252-001
(10) Hinge assembly (includes left and right cables) 793717-001
(11) Kickstand (includes rubber feet) 793715-001
Kickstand Hinge Kit (not illustrated) 793716-001
(12) Bottom cover 793710-001
Rubber Kit (not illustrated, includes bottom cover rubber feet) 804348-001
Miscellaneous parts
Component Spare part number
AC adapter:
65-W HP Smart adapter (non-PFC, EM, 4.5-mm) 714657-001
65-W HP Smart travel adapter (non-PFC) 693716-001
45-W ElitePad HP Smart adapter (4.5-mm) 790129-001
45-W HP Smart adapter (non-PFC, RC, 4.5-mm) 741727-001
45-W HP Smart adapter (non-PFC, RC, 4.5-mm, 2-wire) 742436-001
Bracket Kit:
For use on the keyboard base, includes:
●
Connector board cable
●
Fingerprint reader board cable
●
Smart card reader board cable
793712-001
For use on the slate, includes:
●
Alignment guide left bracket
●
Alignment guide right bracket
●
Docking connector board bracket
●
Volume button board bracket
793728-001
Cable Kit:
For use on the keyboard base, includes:
●
Connector board cable
●
Fingerprint reader board cable
●
Smart card reader board cable
793719-001
26 Chapter 3 Illustrated parts catalog

HP Elite x2 1011 G1 Specifications

General

Stepping	F0
Tjunction	95 °C
Processor code	SR23L
Processor cache	4 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ M
Processor series	Intel Core M-5Y Mobile series
Processor threads	4
Processor codename	Broadwell
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor package size	30 x 16.5 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.6 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	14 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Scenario Design Power (SDP)	3.5 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	256 GB
Display diagonal	11.6 \
Touch technology	Multi-touch
Graphics card	HD Graphics 5300
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Processor ARK ID	84669
Processor socket	BGA 1234
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	-
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery capacity	- mAh
Battery life (max)	9 h
Platform	Windows
Operating system installed	Windows 8.1 Pro

Weight and Dimensions

Depth	192.7 mm
Width	298 mm
Height	10.7 mm
Weight	780 g
