Description
Internal PCIe storage
256-GB solid-state drive, 2280SS, PCIe, NVMe
128-GB solid-state drive, 2280SS, PCIe, NVMe
Hard disc drive
The hard disk drive is located on the left side of the computer.
One 2.5 inch primary hard disk drive (HDD) is installed in the computer. Some models may have a secondary
2.5 inch hard drive installed on top of the optical disc drive (ODD).
●
Removing a 2.5-inch hard disc drive
●
Installing a 2.5-inch hard disc drive
Removing a 2.5-inch hard disc drive
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 31).
2. Remove the rear port cover (see Rear port cover on page 31).
3. Remove the stand (see Attaching and removing a stand on page 32).
4. Remove the access panel (see Access panel on page 37).
5. Disconnect the power and data cables from the hard drive.
6. Pull the hard drive cage latch away from the 2.5 inch hard drive to release the drive (1).
7. Slide the hard drive toward the latch and lift the hard drive out of the drive cage (2).
Drives 39
