Power supply
Description
200W for use in models with discrete graphics
160W for use in models with UMA graphics
The power supply is located in the middle of the computer under the VESA mounting plate.
To remove the power supply:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 31).
2. Remove the rear port cover (see Rear port cover on page 31).
3. Remove the stand (see Attaching and removing a stand on page 32).
4. Remove the access panel (see Access panel on page 37).
5. Remove the system board shield (see System board (EMI) shield on page 48).
6. Remove the VESA mounting bracket (see VESA mounting bracket on page 75).
7. Disconnect the power supply cable from the system board connector (1).
Power supply 77
