8. Remove the four mounting screws from the 2.5 inch hard drive. Be sure to keep the screws together with
the blue rubber grommets to use to install a replacement drive.
9. Remove the 2.5-inch hard disc drive(s) from the cage.
For instructions on installing a hard disc drive, see Installing a 2.5-inch hard disc drive on page 40.
Installing a 2.5-inch hard disc drive
1. Fasten four mounting screws with grommets onto the 2.5 inch hard drive.
2. Position the 2.5 inch drive above the drive cage with the connectors facing the power and data cables
next to the drive cage.
40 Chapter 4 Removal and Replacement Procedures
