PCI-Express M.2 Solid-State Drive
Description
256-GB solid-state drive, 2280SS, PCIe, NVMe
128-GB solid-state drive, 2280SS, PCIe, NVMe
The optional PCI-Express M.2 SSD is located near the bottom of the system board. The drive is secured with
one Phillips screw.
To remove the PCI-Express M.2 SSD:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 31).
2. Remove the rear port cover (see Rear port cover on page 31).
3. Remove the stand (see Attaching and removing a stand on page 32).
4. Remove the access panel (see Access panel on page 37).
5. Remove the system board shield (see System board (EMI) shield on page 48).
6. Remove the Phillips screw (1) that secures the SSD to the computer.
54 Chapter 4 Removal and Replacement Procedures
