HP EliteOne 705 G2 User Manual

Heat sink
Heat sink appearance varies based on processor type and graphics memory.
To remove the heat sink:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 31).
2. Remove the rear port cover (see Rear port cover on page 31).
3. Remove the stand (see Attaching and removing a stand on page 32).
4. Remove the access panel (see Access panel on page 37).
5. Remove the system board shield (see System board (EMI) shield on page 48).
6. Remove the Torx screw on the left part of the heat sink (1).
7. In the order indicated on the heat sink, loosen the silver captive Torx screws (2).
CAUTION: Remove heat sink retaining screws in diagonally opposite pairs (as in an X) to even the
downward forces on the processor. This is especially important as the pins on the socket are very fragile
and any damage to them may require replacing the system board.
Heat sink 59
