6. Remove the jumper from its default position on pins 2 and 3, and place them on pins 1 and 2.
7. After five seconds, remove the jumper from pins 1 and 2, and move it back to the default position on pins 2 and 3.
8.
Install the system board assembly.
9. Install the chassis cover.
10. Connect all peripheral cables to the server.
11. Connect the power cord to the server power jack, and then to the AC source.
12.
Power up the server.
Embedded UEFI Shell
The system BIOS in this server includes an Embedded UEFI Shell in the ROM. The UEFI Shell environment provides an API,
a command-line prompt, and a set of CLIs that allow scripting, file manipulation, and system information. These features
enhance the capabilities of the Aptio Setup Utility.
For more information, see the UEFI Shell Specification on the UEFI website:
Software and configuration utilities
69
