Specifications
Environmental specifications
Specification Value
Temperature range
1
—
Operating
2
10°C to 35°C (50°F to 95°F)
Nonoperating -30°C to 60°C (-22°F to 140°F)
Relative humidity (noncondensing)
—
Operating
10% to 90%
28°C (824°F) maximum web bulb temperature
(noncondensing) across the operating temperature range
of 0°C to 40°C.
Nonoperating
5% to 95%
387°C (1017°F), maximum wet bulb temperature
1
All temperature ratings shown are for sea level. An altitude derating of 10°C per 3048 m (18°F per 1000 ft) to 3048 m (10000 ft) is
applicable. No direct sunlight allowed. Maximum rate of change is 20°C per hour (36°F per hour). The upper limit and rate of change
might be limited by the type and number of options installed.
2
System performance during standard operation might degrade if there is a fan fault or if the internal server temperature is above 30°C
(86°F).
Server specifications
Dimension
Value
Height 2350 cm (925 in)
Depth 2540 cm (1000 in)
Width 2300 cm (906 in)
Weight (approximate values)
Minimum (one drive and one DIMM installed, no media drive or
expansion board installed)
6495 kg (1432 lb)
Maximum (four drives, two DIMMs, optical drive or SSD, and two
expansion boards installed)
969 kg (2136 lb)
Power supply specifications
The server is configured with a non-hot-plug, nonredundant 200 W power supply.
Specifications
81
