Bezel
The bezel is secured with tape underneath. Work around all sides of the bezel, prying it up to remove it. The
webcam is housed on the inside, top of the bezel and has two cables that route to a connector board at the
top of the chassis.
CAUTION: When prying the bezel o the computer, be careful not to ex the bezel too much, which could
result in its breaking.
After you disengage the bezel from the computer, only lift the bezel enough to access the webcam cables
underneath. If you lift the bezel too far o the chassis before disconnecting the cables, you could damage the
connectors.
To remove the bezel:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 17).
2. Pry the bezel o the chassis. Work around all sides of the bezel to disengage the tape that secures the
bezel to the chassis. Do NOT lift the bezel completely o the computer.
Bezel 23
