HP OFFICEJET 200 User Manual

NOTE: To set print settings for all print jobs, make the changes in the HP software provided with the
printer. For more information on the HP software, see Printer management tools.
5. On the Layout tab or Paper/Quality tab, click the Advanced button.
6. In the Paper/Output area, select the custom size from the Paper Size drop-down list.
NOTE: If you change the paper size, be sure to load the correct paper in the input tray and set the
paper size on the printer control panel.
7. Select any other print settings that you want, and then click OK.
8. Click Print or OK to begin printing.
To print on special or custom-size paper (OS X)
Before you can print on custom-size paper, you must set up the custom size in the HP software.
1. Load the appropriate paper in the tray.
2. Create the new custom paper size.
a. In the software you want to print from, click File, and then click Print.
b. Make sure your printer is selected.
c. Click Manage Custom Sizes in the Paper Size pop-up menu.
If you do not see options on the Print dialog, click Show Details.
d. Click +, and then select the new item in the list and type a name for the custom paper size.
e. Enter the height and width for your custom paper.
f. Click Done or OK, and then click Save.
3. Use the created custom paper size to print.
a. From the File menu in your software application, click Print.
b. Make sure your printer is selected.
c. Choose the custom paper size name you created in the Paper Size pop-up menu.
d. Select any other print settings you want, and then click Print.
NOTE: Software and system requirements can be found in the Readme le, which is available on the HP
printer software CD provided with your printer.
Print on both sides
To print on both sides (Windows)
To print on both sides, you must do it manually. Automatic duplexing is not supported with this printer.
1. Load paper in the tray. For more information, see Load paper.
2. From the File menu in your software, select Print.
A Print window opens.
3. Select your printer.
4. Specify the page range and the number of copies you want to print.
24 Chapter 3 Print ENWW

HP OFFICEJET 200 Specifications

General

Color	Yes
HP segment	Small medium business
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	500 pages per month
Duplex printing mode	Manual
Recommended duty cycle	100 - 300 pages per month
Number of print cartridges	2
Page description languages	PCL 3 GUI
Maximum resolution	4800 x 1200 DPI
Print resolution black	1200 x 1200 DPI
Time to first page (black, normal)	12 s
Time to first page (color, normal)	14 s
Print speed (black, draft quality, A4/US Letter)	20 ppm
Print speed (color, draft quality, A4/US Letter)	19 ppm
Print speed (black, normal quality, A4/US Letter)	10 ppm
Print speed (color, normal quality, A4/US Letter)	7 ppm
Control type	Buttons
Color display	No
Product color	Black
Display diagonal	2 \
Country of origin	Thailand
Market positioning	Home & office
Memory type	DDR3
Sound power level (printing)	5.4 dB
Mobile printing technologies	HP ePrint
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.8 Mountain Lion
Recommended system requirements	Windows 10, 8.1, 8, 7, Windows Vista: (32-bit only), Windows XP SP3; AppleOS X Yosemite (v10.10), OS X Mavericks (v10.9), OS X Mountain Lion (v10.8); Linux
Other operating systems supported	Linux, ChromeOS
Windows operating systems supported	Windows 8.1, Windows Vista, Windows 7, Windows XP, Windows 8, Windows 10
Total input capacity	50 sheets
Envelopes sizes	B5, C5, C6, DL
Photo paper sizes	10x15 cm
Custom media width	76.2 - 101 mm
Maximum print size	209.9 x 349.6 mm
Custom media length	216 - 355.6 mm
Paper tray media types	Glossy paper, Matte paper, Photo paper, Plain paper, Recycled paper, Thick paper
Paper tray media weight	60 - 300 g/m²
Non-ISO print media sizes	L, 2L
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5, C6
Borderless printing media sizes	13x18
Maximum ISO A-series paper size	A4
AC input voltage	200 - 240 V
AC input frequency	50/60 Hz
Power consumption (off)	0.17 W
Power consumption (standby)	3.9 W
Power consumption (printing)	15 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	15 - 95 %
Recommended humidity operating range	15 - 90 %
Package depth	119 mm
Package width	495 mm
Package height	243 mm
Package weight	3600 g
Cables included	AC
Bundled software	HP Dropbox, HP Google Drive, Microsoft DotNet
Included cartridge capacity (CMY)	120 pages
Included cartridge capacity (black)	200 pages
Sustainability certificates	ENERGY STAR, EPEAT Silver
Pallet weight	741 g
Quantity per pallet	200 pc(s)
Harmonized System (HS) code	8443321040
Number of layers per pallet	10 pc(s)
Number of cartons per pallet layer	20 pc(s)
Number of users	3 user(s)
Print technology	Thermal inkjet

Weight and Dimensions

Depth	186 mm
Width	364 mm
Height	69 mm
Pallet dimensions (W x D x H)	1219 x 1016 x 2430 mm
