RJ-11 (modem)
Pin Signal
1Unused
2Tip
3Ring
4Unused
5Unused
6Unused
Universal Serial Bus
Pin Signal
1 +5 VDC
2 Data -
3 Data +
4Ground
ENWW
RJ-11 (modem)
117
