Optical drive
NOTE: The optical drive spare part kit includes an optical drive bezel and bracket.
Description Spare part number
LightScribe DVD±R/RW SuperMulti DL Drive 603677–001
Blu-ray ROM with LightScribe DVD±R/RW SuperMulti DL Drive 603678–001
Before removing the optical drive:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the computer.
4. Remove the
Battery on page 43.
5. Remove the
Hard drive cover on page 44.
To remove the optical drive:
1.
Position the computer with the front toward you.
2. Remove the screw (1) that secures the optical drive to the computer.
3. Remove the optical drive (2).
Reverse this procedure to install the optical drive.
52 Chapter 4 Removal and replacement procedures ENWW
