Hard drive
NOTE: The hard drive spare part kit includes left and right bracket rails, a connector cable, Mylar
cover with tab, and four rubber isolators.
Description Spare part number
250 GB, 7200 rpm 603667–001
320 GB, 7200 rpm 603668–001
500 GB, 7200 rpm 603669–001
640 GB, 5400 rpm 603670–001
750 GB, 5400 rpm 603671–001
1 TB, 5400 rpm 603672–001
160–GB solid state drive (SSD) 603673–001
256–GB soild state drive (SSD) 603674–001
Hard Drive Hardware Kit (includes left and right bracket rails, connector cable, Mylar cover
with tab, and four rubber isolators)
603676–001
Before removing the hard drive:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the computer.
4. Remove the
Battery on page 43.
5. Remove the
Hard drive cover on page 44.
To remove the hard drive:
1. Position the computer with the front toward you.
2. Disconnect the hard drive cable (1) from the system board.
ENWW
Component replacement procedures
45
