Touchscreen display assembly
NOTE: The display assembly includes a webcam, two microphones, and two wireless antenna
transceivers and cables.
Description Spare part number
39.6-cm (15.6-inch) HD Touchscreen display assembly with low light VGA webcam and two
microphones (Etched)
595132–001
Before removing the display assembly:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the computer.
4. Remove the following components:
a.
Battery on page 43
b.
Hard drive cover on page 44
c.
Hard drive on page 45
d.
WLAN module on page 47
e.
Optical drive on page 52
f.
Keyboard on page 53
g.
Top cover on page 55
To remove the Touchscreen display assembly:
1. Remove the WLAN cables (1) from under the system board.
2.
Disconnect the display panel cable (2) from the system board.
60 Chapter 4 Removal and replacement procedures ENWW
