Hard drive cover
Description Spare part number
Hard drive cover (included in the Plastics Kit) 603679-001
Before removing the hard drive cover:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC outlet
and then disconnecting the AC adapter from the computer.
4. Remove the
Battery on page 43.
To remove the hard drive cover:
1. Loosen the four captive screws (1) that secure the hard drive cover to the computer.
2. Lift the hard drive cover (2) away from the computer.
Reverse this procedure to install the hard drive cover.
44 Chapter 4 Removal and replacement procedures ENWW
