Power button
Table 5-8 Power button description and part numbers
Description Spare part number
Power button, mineral silver L54104-001
Power button, warm gold L54104-002
Power button, cloud blue L54104-003
Power button, pale gold L54104-004
Power button, natural silver L54104-005
Before removing the power button, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 30).
2. Remove the bottom cover (see Bottom cover and Rubber Foot Kit on page 31).
3. Remove the battery (see Battery on page 34).
Remove the power button:
1. Push the power button into the computer (1).
2. Remove the power button arms (2) from the clips (3) that secure the power button to the computer.
3. Remove the power button from the computer (4).
Reverse this procedure to install the power button.
Component replacement procedures 45
