Fingerprint reader board
Table 5-12 Fingerprint reader board descriptions and part numbers
Description Spare part number
Fingerprint reader board, ash silver L51113-001
Fingerprint reader board, natural silver L51840-001
Fingerprint reader board, luminous gold L51841-001
Before removing the ngerprint reader board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 30).
2. Remove the bottom cover (see Bottom cover and Rubber Foot Kit on page 31).
3. Remove the battery (see Battery on page 34).
4. Remove the hard drive (see Hard drive and hard drive cover on page 37).
Remove the ngerprint reader board:
1. Disconnect the cable from the reverse ZIF connector on the ngerprint reader board (1).
2. Remove the Phillips M2.0 × 2.0 screw (2) that secures the ngerprint reader board bracket to the
computer.
3. Slide the bracket toward the side of the computer, and then remove it (3).
4. Remove the ngerprint reader board from the computer (4).
Reverse this procedure to install the ngerprint reader board.
52 Chapter 5 Removal and replacement procedures for authorized service provider parts
