HP ProLiant ML150 Generation 2 User Manual

Removal and Replacement Procedures
2-8 HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 6/10/05 4:28 PM
Access Panel
To remove the access panel:
1. Complete the preparation procedures. Refer to “Preparation Procedures” earlier in this
chapter.
2. Loosen the two thumbscrews located on the right of the rear of the chassis (1).
3. Slide the access panel back about 1.5 cm (0.5 inch) (2).
4. Detach the top edge of the access panel from the chassis about 30 degrees, and then pull
up to remove the access panel (3).
Figure 2-3: Removing the access panel
To replace the access panel, reverse steps 2 through 4.
