Removal and Replacement Procedures
2-20 HP ProLiant ML150 Generation 2 Server Maintenance and Service Guide
HP CONFIDENTIAL Codename: Stone Soup 2 Part Number: 368148-003 Last Saved On: 6/10/05 4:28 PM
CD-ROM Drive
To remove the CD-ROM drive:
1. Complete the preparation procedures. Refer to “Preparation Procedures” earlier in this
chapter.
2. Open the bezel door. Refer to “Bezel Door” earlier in this chapter.
3. Press the two release tabs of the rails inward and slide the drive out far enough to expose
the connectors.
4. Disconnect the power and signal cable connectors.
5. Hold the drive by its sides and gently slide the drive out of the drive bay.
Figure 2-18: Removing the CD-ROM drive
