Fabric OS Administrator’s Guide 443
53-1002446-01
F_Port trunking
22
F_Port trunking for Access Gateway
You can configure trunking between the F_Ports on an edge switch and the N_Ports on an Access
Gateway module.
You cannot configure F_Port trunking on the F_Ports of an Access Gateway module.
F_Port trunking keeps F_Ports from becoming disabled when they are mapped to an N_Port on a
switch in Access Gateway mode. With F_Port trunking, any link within a trunk can go offline or
become disabled, but the trunk remains fully functional and there are no reconfiguration
requirements.
Figure 70 shows a switch in AG mode without F_Port masterless trunking. Figure 71 shows a switch
in AG mode with F_Port masterless trunking.
FIGURE 70 Switch in Access Gateway mode without F_Port trunking
FIGURE 71 Switch in Access Gateway mode with F_Port masterless trunking
