HP zbook 15 G3 User Manual

I/O devices
NOTE:
●
Make sure external devices are supported and compliant (i.e., USB Type C, Thunderbolt 3, PCI Express,
etc).
●
If you have problems with external devices not provided by HP, contact device manufacturers for
compatibility and latest drivers prior to troubleshooting (i.e., USB devices, Thunderbolt devices, PCI
Express Card reader, VGA/Display/HDMI monitors, Speakers, etc).
●
Be sure I/O devices are properly inserted into the I/O ports, and then be sure the I/O devices are
recognized by Windows Device Manager.
Keyboard
Symptoms
Keystrokes not recognized
Characters not matched
Possible causes
Dust trapped under keycap, loose keycap, loose keyboard connection, defective keyboard.
Troubleshooting steps
1. Inspect the keyboard for any signs of dust, liquid, or debris trapped under sticky keys
that might prevent keystroke recognition.
2. Check for incomplete connection between keyboard and system board by verifying that
caps lock or num lock light turns on when key is pressed.
3. Verify whether the keyboard is recognized in Windows Device Manager and verify
whether the keyboard driver is installed properly.
4. Test with a working external keyboard (i.e., USB keyboard).
Also test in Windows for special keys (Caps Lock, Shift, Ctrl, Fn, Windows, Alt) if
necessary.
5. Test with HP PC Hardware Diagnostics (UEFI) to isolate a hardware issue from a
software issue.
6. Verify that BIOS is up to date. If so, resetting BIOS to default may help.
7. Test with veried working operating system or restore operating system to be sure that
the issue is not caused by dierent language settings, sticky keys feature, etc.
8. Verify that keyboard ex cables are fully inserted and in good condition.
The sections below are intended for authorized service providers/technicians.
1. Verify if keyboard ex cable is in good condition (no delamination or torn cable end, no
missing or cracked tracks, pads).
2. Verify keyboard ex cable ends are fully inserted and aligned with connectors on
system board, and those connector tabs are properly closed. Reseat cables.
3. Replace new internal keyboard and retest.
Tips and tricks A key only works when pressed with force. Inspect and remove debris trapped under keycap.
Common issues and possible solutions 119

HP zbook 15 G3 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Cable lock slot	Yes
Country of origin	China
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-6700HQ
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6700 Mobile series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1866, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
Motherboard chipset	Intel CM236
Pointing device	Touchpad
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® M2000M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Battery capacity	90 Wh
Number of battery cells	9
AC adapter power	150 W
Number of built-in speakers	2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Processor code	SR2FQ
Processor ARK ID	88967
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	264 mm
Width	386 mm
Height	26 mm
Weight	2590 g
