Solid-state drive (SSD)
Table 5-5 Solid-state drive (SSD) description and number
Description Spare part number
2 TB, PCIe, NVMe, TLC L25103-001
1 TB, PCIe, NVMe, TLC L25099-001
1 TB, Z Turbo Drive L25106-001
1 TB, SATA-3, TLC L25109-001
512 GB, PCIe, NVMe, TLC L25105-001
512 GB, Z Turbo Drive L25108-001
512 GB, PCIe, NVMe, self-encrypting drive, Opal 2, TLC L25104-001
256 GB, Z Turbo Drive L25107-001
256 GB, PCIe, NVMe, TLC L25101-001
256 GB, PCIe, NVMe, self-encrypting drive, Opal 2, TLC L25100-001
256 GB, SATA-3, self-encrypting drive, Opal 2, TLC L25102-001
256 GB, SATA-3, TLC L25110-001
Before removing the solid-state drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 38).
5. Remove the battery (see Battery on page 40).
Remove the solid-state drive:
▲ Remove the Phillips M2.0×3.0 screw (1), and then pull the drive from the socket (2).
46 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
