22 TECHNICAL DATA
149
Screw, top shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Nut, angle lever on swingarm M14x1.5 80 Nm (59 lbf ft)
Nut, linkage lever on angle lever M14x1.5 80 Nm (59 lbf ft)
Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft)
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft)
Loctite
®
243™

Husqvarna TX 125 Specifications

General

Displacement	124.8 cc
Bore x Stroke	54 mm x 54.5 mm
Starter	Kickstarter
Transmission	6-speed
Seat Height	960 mm
Ground Clearance	370 mm
Engine Type	Single cylinder, 2-stroke
Rear Suspension	WP XACT shock absorber with linkage
Front Brake	260 mm disc
Rear Brake	220 mm disc
Clutch	Wet, multi-disc clutch, hydraulically operated
