Husqvarna TX 125 User Manual

TABLE OF CONTENTS
3
9.5 Braking................................................ 37
9.6 Stopping, parking ............................... 38
9.7 Transporting........................................ 38
9.8 Refueling............................................. 39
10 SERVICE SCHEDULE...................................... 41
10.1 Additional information......................... 41
10.2 Required work..................................... 41
10.3 Recommended work........................... 42
11 TUNING THE CHASSIS................................... 43
11.1 Checking the basic chassis setting
with the rider's weight......................... 43
11.2 Compression damping of the shock
absorber.............................................. 43
11.3 Adjusting the low-speed
compression damping of the shock
absorber.............................................. 43
11.4 Adjusting the high-speed
compression damping of the shock
absorber.............................................. 44
11.5 Adjusting the rebound damping of
the shock absorber............................. 45
11.6 Measuring the rear wheel dimension
unloaded............................................. 45
11.7 Checking the static sag of the
shock absorber................................... 46
11.8 Checking the riding sag of the
shock absorber................................... 46
11.9 Adjusting the spring preload of the
shock absorber ............................... 47
11.10 Adjusting the riding sag .................. 48
11.11 Checking the basic setting of the
fork...................................................... 48
11.12 Adjusting the compression damping
of the fork............................................ 49
11.13 Adjusting the rebound damping of
the fork................................................ 49
11.14 Adjusting the spring preload of the
fork...................................................... 50
11.15 Handlebar position.............................. 51
11.16 Adjusting the handlebar position .... 51
12 SERVICE WORK ON THE CHASSIS ............... 53
12.1 Raising the motorcycle with a lift
stand ................................................... 53
12.2 Removing the motorcycle from the
lift stand .............................................. 53
12.3 Bleeding the fork legs ......................... 53
12.4 Cleaning the dust boots of the fork
legs ..................................................... 54
12.5 Removing the fork legs ................... 54
12.6 Installing the fork legs ..................... 55
12.7 Removing the fork protector............... 56
12.8 Installing the fork protector................. 56
12.9 Removing the lower triple clamp .... 56
12.10 Installing the lower triple clamp ...... 57
12.11 Checking the play of the steering
head bearing....................................... 59
12.12 Adjusting the play of the steering
head bearing ................................... 60
12.13 Greasing the steering head
bearing ............................................ 60
12.14 Removing front fender ........................ 61
12.15 Installing front fender .......................... 61
12.16 Removing the shock absorber ........ 62
12.17 Installing the shock absorber .......... 63
12.18 Removing the seat .............................. 65
12.19 Mounting the seat............................... 66
12.20 Removing the air filter box cover........ 66
12.21 Installing the air filter box cover.......... 67
12.22 Removing the air filter ..................... 67
12.23 Cleaning the air filter and air filter
box .................................................. 68
12.24 Installing the air filter ....................... 68
12.25 Sealing the air filter box .................. 69
12.26 Removing the main silencer................ 69
12.27 Installing the main silencer.................. 70
12.28 Changing the glass fiber yarn filling
in the main silencer ......................... 70
12.29 Removing the right side cover ............ 71
12.30 Installing the right side cover.............. 71
12.31 Removing the fuel tank ................... 71
12.32 Installing the fuel tank ..................... 73
12.33 Checking the chain for dirt.................. 74
12.34 Cleaning the chain .............................. 74
12.35 Checking the chain tension ................ 75
12.36 Adjusting the chain tension................. 76
12.37 Checking the chain, rear sprocket,
engine sprocket, and chain guide....... 77
12.38 Checking the frame ......................... 79
12.39 Checking the swingarm .................. 79
12.40 Checking throttle cable routing .......... 79
12.41 Checking the rubber grip .................... 80
12.42 Adjusting the basic position of the
clutch lever.......................................... 81
12.43 Checking/correcting the fluid level
of the hydraulic clutch ........................ 81
12.44 Changing the hydraulic clutch
fluid ................................................. 82
12.45 Removing the engine guard................ 83
12.46 Installing the engine guard.................. 84

Husqvarna TX 125 Specifications

General

Displacement	124.8 cc
Bore x Stroke	54 mm x 54.5 mm
Starter	Kickstarter
Transmission	6-speed
Seat Height	960 mm
Ground Clearance	370 mm
Engine Type	Single cylinder, 2-stroke
Rear Suspension	WP XACT shock absorber with linkage
Front Brake	260 mm disc
Rear Brake	220 mm disc
Clutch	Wet, multi-disc clutch, hydraulically operated
