212 ArcGlide THC Instruction Manual 806450
4 – Maintenance
J7 RJ45
Pin No. Signal Pin No. Signal
1 Tx + (transmit data +) 2 Tx - (transmit data -)
3 Rx + (receive data +) 4 Not connected
5 Not connected 6 Rx - (receive data -)
7 Not connected 8 Not connected
J8 Front panel LEDs
Pin No. Signal Pin No. Signal
1 +LED V 2 +LED V
3 Start LED 4 Motion LED
5 Limit LED 6 AVC LED
7 Error LED 8 Contact LED
9 Spare1 LED 10 Spare1 LED
J9 Display
Pin No. Signal
1 +5 V
2 Ground
3 Not connected
J10 IHS test push button
Pin No. Signal
1 Ground
2 IHS test
J11 Front panel rotary encoder input
Pin No. Signal
1 Ground
2 Ground
3 Pushbutton-A
4 Output B
5 Output A
6 +5 V
