Hypertherm ArcGlide THC User Manual

280 ArcGlide THC Instruction Manual 806450
B – ArcGlide THC Serial Communication Installation
Cables
Plasma I/O split cable (Z) (223253)
Connector A
Pin No.
Wire color Signal
Connector C
Pin No.
6
7
White
Black
Motion input +
Motion input -
28
9
18
19
White
Brown
Pierce output A
Pierce output B
13
32
Length = 476.25 mm (18.75 inch)
Diameter = 12.70 mm (0.50 inch)
Bend radius = 152.40 mm (6.00 inch)
Routes serial signals from the plasma I/O board to the CNC.
Connects the CNC I/O board to the CNC cable.
Length = 476.25 mm (18.75 inch)
Diameter = 12.70 mm (0.50 inch)
Bend radius = 152.40 mm (6.00 inch)
Connector C
Connector D
Connector A
Connector B
Ye ll ow
Blue
Black
Diameter = 6.60 mm (0.26 inch)
Bend radius = 152.40 mm (6.00 inch)
Connects the plasma I/O board to the plasma cable.
Connector A
Connector C
1
20
19
37
1
4
5
10
16
23
29
34
9
15
22
28
33
37
1
20
19
37
Connector D
